Caravan Weights Explained

Have you been left scratching your head after hearing about payload, ATM, GCM, TBM, tare? There’s a lot to consider when it comes to how much you can put in your caravan, and what vehicle can safely tow your van as well. An overweight camper, pop-top hybrid or caravan is not only dangerous, it can also void your insurance in an accident.
Here’s What You Need TO Know
Caravan 10 1
Tare | TARE MAss
Tare mass is the base weight of the caravan or camper at the time of manufacture without any payload or after-market accessories, without water in the tanks or the gas bottles filled.
ATM | Aggregate Trailer Mass
ATM (Aggregate Trailer Mass) is the manufacturer’s maximum specified weight of your loaded caravan or camper and is measured unhitched and sitting on its jockey wheel and axle(s).
Payload
Payload is all the bits you add on or load up to take away (this also includes your filled gas bottles and water tanks).
Caravan 11 1
Caravan 12 1
GTM | Gross Trailer Mass
GTM (Gross Trailer Mass) is the maximum weight your caravan or camper can be at its axle(s) and is sometimes referred to as the axle capacity. Generally, this is measured while the caravan or camper wheels are sitting on a weighbridge but the hitched tow vehicle is not.
TBM | Tow Ball Mass
TBM (Tow Ball Mass) is the effective mass on the tow ball from the trailer hitch. The maximum TBM is not typically specified by the manufacturer but as a guide should be up to 10% of the ATM.
GCM | Gross Combined Mass
GCM (Gross Combined Mass) is when you weigh your tow vehicle and your caravan or camper when they are fully loaded.
Caravan 13 2
